Lift ST - Lift control cable with steel center as suspension unit |
 |
| |
Construction |
|
|
| |
Conductor |
|
bare copper stands, |
| |
|
|
fine wires acc. to DIN VDE 2095 class 6, |
| |
|
|
table 4, column 3 |
| |
Insulation |
|
special PVC |
| |
Core code |
|
Black core with white consecutive number |
| |
|
|
and green-yellow earth wire |
| |
Strain relief |
|
steel rope in the center |
| |
Standing |
|
steel rope as core, |
| |
|
|
optimized twisting of conductors in layers |
| |
Supporting braid |
|
special torsion protecting net |
| |
Sheath material |
|
black (RAL 9005) |
| |
|
|
|
| |
Technical data |
|
|
| |
Nominal voltage |
|
Uo/U : 300/500V |
| |
Testing voltage |
|
conductor/cinductor 2000V |
| |
Min. bending radius |
|
15 x d |
| |
Temperature range |
|
|
| |
fixed laying |
|
- 5°C + 50°C |
| |
flexible application |
|
-40°C + 70°C |
| |
Firs performance |
|
flame-retardant |
| |
Suspended height |
|
up to 200m |
| |
|
|
|
| |
Product advantages |
|
|
| |
highest hanging lengths |
|
|
| |
ong service life |
|
|
| |
 |
| |
